Specifications

Santa Fe 2.5 Petrol AWD

Santa Fe 2.5 Petrol AWD

Santa Fe 2.5 Petrol Elite AWD

Santa Fe 2.5 Petrol Elite AWD

Santa Fe 2.5 Petrol Limited AWD

Santa Fe 2.5 Petrol Limited AWD

Santa Fe 2.2 Diesel AWD

Santa Fe 2.2 Diesel AWD

Santa Fe 2.2 Diesel Elite AWD

Santa Fe 2.2 Diesel Elite AWD

Santa Fe 2.2 Diesel Limited AWD

Santa Fe 2.2 Diesel Limited AWD

Santa Fe 3.5 V6 Petrol Limited 2WD

Santa Fe 3.5 V6 Petrol Limited 2WD

Engine

Engine Type
2.5 litre 16 valve twin overhead cam with multi-point fuel injection engine with CVVT (Continuously Variable Valve Timing)
2.5 litre 16 valve twin overhead cam with multi-point fuel injection engine with CVVT (Continuously Variable Valve Timing)
2.5 litre 16 valve twin overhead cam with multi-point fuel injection engine with CVVT (Continuously Variable Valve Timing)
2.2 litre 16 valve twin overhead cam with common rail direct injection and variable geometry turbocharger
2.2 litre 16 valve twin overhead cam with common rail direct injection and variable geometry turbocharger
2.2 litre 16 valve twin overhead cam with common rail direct injection and variable geometry turbocharger
3.5 litre V6 24 valve twin overhead cam with multi-point fuel injection engine with CVVT (Continuously Variable Valve Timing)
Fuel system
Multi-Point Injection (MPI)
Multi-Point Injection (MPI)
Multi-Point Injection (MPI)
Common Rail Direct Injection (CRDi)
Common Rail Direct Injection (CRDi)
Common Rail Direct Injection (CRDi)
Multi-Point Injection (MPI)
Displacement (CC)
2,497
2,497
2,497
2,151
2,151
2,151
3,470
Maximum power (kW/rpm)
132 kW / 6,000 rpm
132 kW / 6,000 rpm
132 kW / 6,000 rpm
148 kW / 3,800 rpm
148 kW / 3,800 rpm
148 kW / 3,800 rpm
200 kW / 6,800 rpm
Maximum torque (Nm/rpm)
232 Nm / 4,000 rpm
232 Nm / 4,000 rpm
232 Nm / 4,000 rpm
440 Nm / 1,750-2,750 rpm
440 Nm / 1,750-2,750 rpm
440 Nm / 1,750-2,750 rpm
331 Nm / 5,000 rpm

Transmission

Transmission type
6 Speed Automatic
6 Speed Automatic
6 Speed Automatic
8 Speed Dual Clutch Transmission (Wet Clutch Type)
8 Speed Dual Clutch Transmission (Wet Clutch Type)
8 Speed Dual Clutch Transmission (Wet Clutch Type)
8 Speed Automatic
Downhill Brake Control (DBC)
Hill-start Assist Control (HAC)
Electronic Shift By Wire gear selector (SBW)
Paddle shifters

Chassis

Drive system
All Wheel Drive with HTRAC
All Wheel Drive with HTRAC
All Wheel Drive with HTRAC
All Wheel Drive with HTRAC
All Wheel Drive with HTRAC
All Wheel Drive with HTRAC
Front Wheel Drive
Front suspension
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
MacPherson strut suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Rear suspension
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Multi-link suspension with coil springs, gas-filled shock absorbers and anti-roll stabiliser bar
Drive mode system
Normal, Eco, Sport & Smart modes
Normal, Eco, Sport & Smart modes
Normal, Eco, Sport & Smart modes
Normal, Eco, Sport & Smart modes
Normal, Eco, Sport & Smart modes
Normal, Eco, Sport & Smart modes
Terrain mode system
Snow, Mud, Sand modes
Snow, Mud, Sand modes

Wheels and Braking System

Wheels
18" Alloy
20" Alloy
20" Alloy
18" Alloy
20" Alloy
20" Alloy
20" Alloy
Tyres
235 / 60 R18
255 / 45 R20
255 / 45 R20
235 / 60 R18
255 / 45 R20
255 / 45 R20
255 / 45 R20
Full size alloy spare wheel & tyre
Tyre Pressure Monitoring System (TPMS)
Braking system
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Power assisted braking system with ventilated front disc and solid rear disc brakes with ABS, EBD and BAS
Electronic Parking Brake (EPB)

Steering

Type
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Motor Driven Power Steering (MDPS)
Steering column
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Manual tilt & telescopic adjustment
Minimum turning circle diameter (m) - kerb to kerb
5.7
5.7
5.7
5.7
5.7
5.7
5.7
Energy absorbing collapsible steering column

Safety Features

ABS braking with Electronic Brake-force Distribution (EBD)
Brake Assist System (BAS)
Electronic Stability Control (ESC)
Traction Control System (TCS)
Vehicle Stability Management (VSM)
Forward Collision-Avoidance with Junction Assist (FCA-JX)
Reversing Collision Avoidance assist (RCA)
Blind-spot Collision Avoidance assist (BCA)
Blind-spot View Monitor system (BVM)
Rear Cross-traffic Collision Avoidance assist (RCCA)
Lane Keeping Assist (LKA)
Lane Following Assist (LFA)
Smart Cruise Control with stop & go (SCC)
High Beam Assist (HBA)
Driver Attention Alert (DAA)
Safe Exit Assist (SEA)
Rear Occupant Alert (ROA)
6 Airbags (dual front, side, curtain airbags)
Front seatbelt pretensioners and load limiters
3-point tether child seat anchor points
ISOFIX child seat anchor points
Height adjustable seatbelts (front)
3-point lap diagonal (ELR) seatbelts
Power operated child safety rear door locks
Electro-Chromatic Rear-view Mirror (ECM)
Automatic dusk sensing headlights
Rain sensing wiper system
Remote Smart Park Assist (RSPA)
Rear park assist system
Front park assist system
Reversing camera
Surround View Monitor (SVM)
First aid kit

Exterior Features

Panoramic sunroof
Smart power tailgate
Electrically adjustable side mirrors
Electric folding side mirrors
Heated side mirrors
LED head lights (low-beam)
Bi-LED head lights
LED Daytime Running Lights (DRL)
LED tail lights
Rear spoiler with high mounted LED stop light
Privacy glass
Laminated acoustic windscreen
Satin chrome exterior trim
Mud guards
Roof rails

Interior Features

7 Seats
Cloth interior trim
Full leather interior trim **
Leather steering wheel and gearshift trim **
Premium cloth pillar & roof lining
Driver seat 10-way electric adjustment
Driver seat 14-way electric adjustment
Passenger seat 8-way electric adjustment
Driver memory seat function
Heated front (3-stage) & outboard 2nd row seats (2-stage)
Ventilated front seats (3-stage)
Power windows
Wireless smart phone charging ***
Head-Up Display (HUD)
LED interior lighting
2nd & 3rd row split folding function

Security

Proximity key and engine start / stop button
Keyless entry with anti-theft alarm
Engine immobiliser
Hyundai Active Locking Operation (HALO) including speed sensing auto door locking

Comfort and Convenience

8" touch screen audio system with radio, MP3 functionality
10.25" touch screen audio system with satellite navigation, radio, MP3 functionality
Apple CarPlay® & Android Auto® compatibility
Harman Kardon 10 speaker premium audio system including subwoofer
4 speakers and 2 tweeters
Bluetooth voice recognition handsfree phone system
Steering wheel mounted audio and cruise controls
2 x front USB input
2 x 2nd row USB input
3rd row USB input
Dual zone climate control air-conditioning with pollen filter
3rd row air conditioning
Automatic windscreen defog
Trip computer including distance to empty, average fuel consumption, average speed and outside temperature display
12.3" Colour TFT driver information display
Illuminated vanity mirror in driver and front passenger sunvisors

Auto Link car connectivity - Bluetooth enabled

Past driving history including driving statistics & location monitoring
Remote vehicle monitoring including tyre pressures, fuel level & location
Accident & emergency assistance

Auto Link Premium car connectivity - SIM enabled

Remote vehicle functions including security, engine starting & air-conditioning
Optional
Optional
Optional
Optional
Geo-fencing enabled
Optional
Optional
Optional
Optional
Guard & valet modes
Optional
Optional
Optional
Optional

Weights and Capacities

Fuel tank capacity (litres)
67
67
67
67
67
67
67
Boot capacity (VDA litres) - 3rd row down
571
571
571
571
571
571
571
Kerb weight (kg) lightest / heaviest
1,725 / 1,846
1,725 / 1,846
1,725 / 1,846
1,820 / 1,943
1,820 / 1,943
1,820 / 1,943
1,735 / 1,858
Towing capacity - braked (kg)
2,000
2,000
2,000
2,500
2,500
2,500
2,500
Towing capacity - unbraked (kg)
750
750
750
750
750
750
750

Exterior Dimensions

Wheelbase (mm)
2,765
2,765
2,765
2,765
2,765
2,765
2,765
Overall length (mm)
4,785
4,785
4,785
4,785
4,785
4,785
4,785
Overall width (mm)
1,900
1,900
1,900
1,900
1,900
1,900
1,900
Overall height (mm)
1,710
1,710

1,710
1,710
1,710
1,710
1,710
Wheel track - front / rear (mm)
1,646 /  1,656
1,637 / 1,647
1,637 / 1,647
1,646 /  1,656
1,637 / 1,647
1,637 / 1,647
1,637 / 1,647
Minimum ground clearance (mm)
176
176
176
176
176
176
176

Sustainability

Combined fuel economy (litres / 100km)*
8.7
8.7
8.7
6.1
6.1
6.1
10.5
CO2 Emissions (g/km)
199
199
199
160
160
160
244

Warranties

10 year / 200,000 km anti perforation corrosion body warranty
3 year / 100,000 km mechanical warranty
3 year / 100,000 km roadside assistance package
Included
Not Included


(Specifications, features, equipment and colours shown on this website are subject to change without notice or obligation).

*Source: Australian Design Rule 81/02 static laboratory combined average city and highway cycle test. Fuel consumption figures are provided as a guide for comparative purposes. Fuel consumption will vary depending on a combination of driving habits and the condition of the vehicle. To find out more information about fuel economy and how to improve fuel economy, visit http://www.eeca.govt.nz

** Finishes specified as leather contain a combination of genuine leather, polyurethane leather (leather substitute) and man-made materials.

Apple CarPlay and Android Auto are registered trademarks.
